Technical Specifications
| Property | Specification |
| Mechanical and environmental | PR1ICC60 |
| Cable | 4 × RG316, 1 × RG174 |
| Operating temperature | −40 °C to +75 °C |
| Operating environment | This antenna is exclusively designed for fixed installations and must not be used on moving objects or in environments with strong vibrations. |
| Mounting | Wall, ceiling, mast |
| Protection class | IP68 |
| Weight | 1500 g |
| RoHS compliant | Yes |
| LTE antenna | |
| Frequency range | 617–960 MHz; 1700–2700 MHz; 3300–4300 MHz |
| Polarisation | Vertical |
| Radiation pattern | Omnidirectional |
| Gain | Maximum 4.5 dBi |
| VSWR | < 2.50 |
| Impedance | 50 Ω |
| Connector type and number | 2 × SMA male |
| GNSS antenna | |
| Frequency range | 1560–1610 MHz |
| Polarisation | RHCP (right-hand circular) |
| Gain | 28 dBi |
| VSWR | < 2.00 |
| Impedance | 50 Ω |
| Connector type and quantity | 1 × SMA male |
| Power consumption | 2.5–6.5 mA |
| Supply voltage | 2.5–6.5 V DC |
| WiFi antenna | |
| Frequency range | 2400–2500 MHz; 4700–6000 MHz |
| Polarisation | Vertical |
| Radiation pattern | Omnidirectional |
| Gain | Maximum 7.5 dBi |
| VSWR | < 2.00 |
| Impedance | 50 Ω |
| Connector type and quantity | 2 × RP-SMA male |
Radiation range
