TELTONIKA RUT301

Name: TELTONIKA RUT301
SKU: RUT301000000
Price: 68.0 EUR
Availability: InStock

(0 review)

RUT301

INDUSTRIAL ETHERNET ROUTER

The RUT301 is one of the most cost-effective industrial Ethernet routers on the IoT market, providing robust network connectivity with advanced security features. This Ethernet router is equipped with five Ethernet ports, two configurable digital I/Os, and a USB 2.0 port for easy integration with industrial machines, business or shop equipment. Additionally, the RUT301 has a pre-configured firewall and supports multiple industrial communication protocols.

68.00 € (Tax excluded)

Add to cart Buy now

Terms and conditions
Shipping: 2-3 business days

RUT301

INDUSTRIAL ETHERNET ROUTER

The RUT301 is one of the most cost-effective industrial Ethernet routers on the IoT market and offers robust network connectivity with advanced security features. This Ethernet router is equipped with five Ethernet ports, two configurable digital I/Os, and a USB 2.0 port for easy integration with industrial machines, business or retail equipment. Additionally, the RUT301 has a pre-configured firewall and supports multiple industrial communication protocols.

INTERFACES

5 x Ethernet ports (10/100 Mbps), digital I/Os and USB 2.0

RMS

For remote management, access and VPN services

SECURITY PACKAGE

Pre-configured firewall and multiple VPN services

DURABLE

Industrial-grade design, resistant to harsh conditions

Product features

HARDWARE	Teltonika
Product code	RUT301000000
EAN code
5G	-
4G/LTE	-
2G/3G	-
CPU	MediaTek, 580 MHz, MIPS 24KEc
RAM	128 MB, DDR2
Flash memory	16 MB serial NOR flash
Power options	4-pin industrial DC power connector, 9 - 30 VDC
Ethernet	5 × RJ45 ports, 10/100 Mbps
Inputs/outputs	2 × digital input, 2 × digital output on the 4-pin power connector
Other	1 × USB host
Status LEDs	1 × WAN-type LED, 4 × LAN status LEDs, 1 × power LED
Operating temperature	-40 tot +75 °C
Housing	Aluminium housing
Dimensions (W × H × D)	100 × 30 × 85 mm
Weight	233 g
Software
Operating system	RutOS (Linux operating system based on OpenWrt)
Network protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On LAN (WOL)
Routing	Static routing, dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), policy-based routing
Firewall	Port forwarding, traffic rules, custom rules, pre-configured firewall rules, DMZ, NAT, NAT-T, NAT helpers, unlimited firewall configuration via CLI
VPN and tunneling	OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale
Monitoring and management	Web interface, CLI, SSH, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS
Cloud oplossingen	RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity
Services	DDNS, Wake On LAN (WOL), web filter, UPNP, network shares (Samba)
Management	Firmware update from file, check firmware on server, configuration profiles, configuration backup
