Technical specifications
| Parameter | Nominal value |
| Manufacturer | Teltonika |
| Type | PR1KCO28 |
| Mounting method | Screw |
| IP protection class Dome | IP65 (excluding cable outlet) |
| Material Dome | ABS |
| Dimensions housing | Ø 110 × 55 mm |
| Cable | 3 × RG174, 3000 mm |
| Operating temperature | -40 °C to +85 °C |
| Weight | 535 ± 10 g |
| UV resistant | Yes |
| RoHS compliant | Yes |
| Frequency range | 698 - 960, 1710 - 2690 MHz |
| Polarisation | Linear |
| Gain | 3.0 dBi |
| VSWR | ≤ 3.0 |
| Impedance | 50 Ω |
| Connector type and number | 2 × SMA male |
| Frequency range | 1575.42 - 1610 MHz |
| Polarisation | RHCP |
| LNA gain | 28 ± 2 dB |
| LNA-noise figure | ≤ 1.5 dB |
| VSWR | ≤ 2.0 |
| Impedance | 50 Ω |
| Supply voltage | 3 - 5 VDC |
| Power consumption | < 15 mA |
| Connector type and number | SMA male |
| Frequency range | 2400 - 2483.5 / 4900 - 5925 MHz |
| Polarisation | Linear |
| Gain | 2.0 dBi |
| VSWR | ≤ 2.5 |
| Impedance | 50 Ω |
| Connector type and number | 2 × RP-SMA male |
